DIN41612欧式插座3X16P 公座90度 C型
Type 2/C Male
SPECIFICATION
MATERIAL
Housing:PBT+30%G.F UL94V-O Color:Champagne
Contacts:Brass
CONTACT PLATING
Gold Plated on Contact Area,Tin Plated On Solder Tail,Ni Under Plated All Over.
ELECTRICAL
Current rating: 2 Amps .
Contact resistance: 20 mΩ initial
Insulation resistance: 1000 MΩ min @ 500 VDC
Dielectric withstanding voltage: 1000 VAC / minute
Operating temperature: -55°C TO +105°C
