DIN41612 欧式插座 348大电流 公座 F型
    DIN41612 欧式插座 348大电流 公座 F型

    • Type F Male

    • SPECIFICATION

      MATERIAL

      Housing:PBT+30%G.F UL94V-O  Color:Champagne

      Contacts:Brass

      CONTACT PLATING

      Gold Plated on Contact Area,Tin Plated On Solder Tail,Ni Under Plated All Over.


      ELECTRICAL

      Current rating: 5.6 Amps .

      Contact resistance: 30 mΩ initial

      Insulation resistance: 1000 MΩ min @ 500 VDC

      Dielectric withstanding voltage: 1000 VAC / minute

      Operating temperature: -55°C TO +105°C
