SPECIFICATION

MATERIAL

Housing:PBT+30%G.F UL94V-O  Color:Champagne

Contacts:Brass

CONTACT PLATING

Gold Plated on Contact Area,Tin Plated On Solder Tail,Ni Under Plated All Over.

ELECTRICAL

Current rating: 2 Amps .

Contact resistance: 20 mΩ initial

Insulation resistance: 1000 MΩ min @ 500 VDC

Dielectric withstanding voltage: 1000 VAC / minute

Operating temperature: -55°C TO +105°C
