Specifications:

  Current Rating:3.0 Amp

  Voltage Rating:250V AC/DC

  Contact resistance:20mΩ Max

  Insulator resistance:1000MΩ min.

  Withstanding Voltage:500V AC/Minute

  Operating Temperature Range:-40°~+105°C

Material And Finish

  Insulator:Polyester,(PBT/PA9T/PA6T UL94V-0)

  Insulator Color:Black

  Contact:Brass

  Contact Plated:See Contact Plated Tab.
