DIN41612 c Type Fmale

• SPECIFICATION

  MATERIAL

  Housing:PBT+30%G.F UL94V-O  Color:Champagne

  Contacts:Phosphor Bronze

  CONTACT PLATING

  Gold Plated on Contact Area,Tin Plated On Solder Tail,Ni Under Plated All Over.




  ELECTRICAL

  Current rating: 2 Amps .

  Contact resistance: 20 mΩ initial

  Insulation resistance: 1000 MΩ min @ 500 VDC

  Dielectric withstanding voltage: 1000 VAC / minute

  Operating temperature: -55°C TO +105°C

Type Q Famale
